one mode may exist for one device.
Introduction
11
ISP JTAG Mode
ISP HV Mode
Project
In-system programming via a JTAG interface.
In-system programming that requires applying a relatively high voltage to
the target device, (12V for example).
An integrated set of information in the ChipProgUSB that completely
describes the target device, properties of the data buffers, programming
options and settings, list of the source and destination files with all their
properties, etc.. Each project that has its own unique name can be stored
and promptly reloaded for immediate execution. Usually a user creates a
project to work with one type of device. Working with projects saves a lot of
time for the initial configuration of the programmer every time you start
working with a new device.
File - Buffer - Target structure
Buffers are intermediate layers between the data in files and the data in the target device. The
ChipProg enables no direct interaction between the files and target devices. All the file operations,
such as loading and saving files are applicable to the buffers only. All the physical manipulations with
the target device memory content pass through the buffers as well. This is a fundamental principle of
the programmer operations with data and devices
Examples of the buffer's layer structures of different devices:
1. In the Intel 87C51FA microcontroller each opened buffer includes two layers: Code and
Encryption table .
2. In the Microchip PIC16F84 microcontroller each opened buffer includes three layers: Code, Data
EEPROMIdentifier locations .
Each buffer layer can be opened for watching or editing by clicking its tab on the top of the buffer
window.
1.2
System Requirements
To run ChipProgUSB and to control a ChipProg programmer, you need an IBM PC-compatible computer
with the following components:
Pentium-III CPU or higher
Windows XP/Vista/7 for the ChipProg-48, ChipProg-40 and ChipProg-ISP programmers in the all
modes
Windows 98/ME for the ChipProg-48, ChipProg-40 and ChipProg-ISP programmers in the basic mode
Windows 2000/XP/Vista/7 for the ChipProg-G4 programmer
Windows XP/Vista/7 for using the Application Control Interface control
256MB of RAM
At least one USB port
A hard drive with at least 200MB of free space
? 2010 Phyton, Inc. Microsystems and Development Tools
